Multi-Use Temp USB PDF Data Logger Alloy Shell
- Regular price
- $247.99
- Regular price
-
- Sale price
- $247.99
- Unit price
- per
- Internal sensor &Self-generated PDF report
- Measurement range -40°C to 125°C/-80°C to 70°C
- Accuracy: Basic ±0.2°C
- Optional ±0.15°C
- Rigid alloy material shell
- PC software for configuration & data analysis & calibration
- Storage capacity of 25920 records
- Non-volatile memory, no data loss when power off
- Low power consumption and long standby time
- Sampling interval: 1 seconds to 24 hours
- 3.6V 2/3 AA high temperature lithium battery, user replaceable
- Protection Class: IP67 & Certification: CE, ROHS, EN12830
- Up to 6 points calibration ensuring the best accuracy
- Calibration report included with each unit
- Test points: 5 points on the report covering the range
Shipping: 3-5 Business Days
Couldn't load pickup availability
Have a question?
Notified by email when this product becomes available
- Description
- Specifications
- Manual and Resources
This rugged, multi-use temperature data logger is engineered with a specially alloyed shell that delivers excellent mechanical strength, thermal resistance, and IP67-rated protection. Built for durability in challenging environments, it ensures reliable temperature monitoring across a wide operating range: -40°C to 125°C (P/N 35158) or -80°C to 70°C (P/N 35161). The internal sensor offers high accuracy of ±0.2°C, with an optional upgrade to ±0.15°C for critical applications. Configuration is streamlined using PoChain software, allowing for immediate or delayed logging start based on user preference.
Once connected to a PC with PoChain installed, the logger enables fast data analysis and versatile export options in XLS, CSV, PDF, TXT, and CIN formats. Data files can be directed to any local or networked storage for regulatory documentation, QA reports, or long-term archival.
Each unit is shipped with a multi-point calibration report from an ISO/IEC 17025:2017 accredited lab, with all measurement data traceable to SI units through NIST. For ongoing reliability, the logger supports 6-point calibration adjustments via PoChain software. Recalibration can be performed by certified labs or STN’s in-house calibration service to maintain long-term measurement accuracy.
With its durable construction and fast thermal response, this logger is ideal for extreme temperature environments such as autoclaves, freezers, environmental chambers, food sterilization, and pharmaceutical cold chain applications.
|
Probe type |
Internal sensor |
|
Unit |
°C, °F |
|
Resolution |
0.1°C |
|
Measurement range |
-40°C to 125°C/-80°C to 70°C |
|
Accuracy |
Basic ±0.2°C, Optional ±0.15°C |
|
Report form |
Tamper-Proof, encrypted PDF data only accessible to authorized users |
|
Export file formats |
pdf, txt, csv, xls, cin |
|
Data storage capacity |
25920/17280 records |
|
Memory |
Non-volatile memory, no data loss when power off |
|
LED indicator on |
Keeping on for 3 minutes after setup |
|
LED indication |
Single flash every 5 secs: recording Double flash every 5 secs: non-recording |
|
Sampling interval |
User configurable from 1s to 24 hrs/10 seconds to 18 hours |
|
High and low alarm values |
User configurable from -40°C to 125°C/-80°C to 70°C |
|
Alarm delay |
User configurable from 0 to 960 mins |
|
Alarm type |
Single time or cumulative, user configurable |
|
Start recording mode |
Start on a pre-set time by software |
|
Stop recording mode |
Automatic stop when the memory is full; When connected to a computer |
|
Real-time data logging |
Available by software EasyDataPro (-40°C to 85°C)/(-40°C to 70°C) |
|
Operation temperature |
-40°C to 125°C/-80°C to 70°C |
|
Storage temperature |
-40°C to 85°C/-40°C to 70°C |
|
Communication interface |
USB 2.0 |
|
PC Software |
Software PoChain (Windows 7/8/Vista/10 32/64bits) website downloadable |
|
Power supply |
3.6V 2/3 AA high temperature battery, user replaceable |
|
Battery life |
2 years @ 15 minutes sampling interval, 25°C |
|
Protection Class |
IP67 |
|
Shell material |
Special alloy |
|
Dimensions/weight |
φ18mm*115mm/95g |
|
Certification and standards |
CE | ROHS | EN12830 |
|
Calibration |
Max. 6 points calibration by software |
|
Calibration report |
Calibration report included with each unit |
|
Test points |
5 points on the report covering the range |
